Specifications of UT310 Series Vibration Testers
| Secifications | UT312 | UT315A |
| Acceleration (O-P) | 0.1～199.9m/s² Frequency response: 10～1500Hz Accuracy: ≤2.0m/s², ≤±10%; ＞2.0m/s², ≤±5% |
0~199.9m/s² Frequency response: 10Hz-10kHz Accuracy: ±(5%+0.2m/s²) |
| Velocity (RMS) | 0.1～199.9mm/s Frequency response: 10～1500Hz Accuracy: ≤2.0mm/s, ≤±10%; ＞2.0mm/s, ≤±5% |
0~19.99cm/s Frequency response: 10Hz~1kHz Accuracy: ±(5%+0.02cm/s) |
| Displacement (P-P) | 1～1999μm Frequency response: 10～500Hz Accuracy: ≤20um, ≤±10%; ＞20um, ≤±5% |
1~1.999mm Frequency response: 10Hz~500Hz Accuracy: ±(5%+0.002mm) |
| Features | ||
| Data hold | √ | |
| Low battery indication | √ | |
| Auto power off | √ | |
| Battery life | Continuous measuring time > 8 hours | |
| Display count | 2000 | |
| General Characteristics | ||
| Power | 9V battery (6F22 ) | |
| Product color | Red and grey | |
| Product net weight | UT311/UT312: 230g; UT315A: 395g | |
| Product size | UT311/UT312: 185mm x 68mm x 30mm; UT315A: 166mm x 80mm x 30mm | |
| Standard accessories | Battery, tool box | |
| Standard individual packing | Gift box, English manual | |
| Standard quantity per carton | UT311/UT312: 5pcs; UT315A: 1pcs | |
| Standard carton measurement | UT311/UT312: 375mm x 307mm x 246mm; UT315A: 305mm x 240mm x 85mm | |
| Standard carton gross weight | UT311/UT312: 5.8kg; UT315A: About 1.2kg | |
